When dust is present, the dust airflow enters the middle box (dust box) through the ventilation duct. When the dust containing gas passes through the outer surface of the plastic burning plate, the dust is trapped on the coating of the outer surface of the plastic burning plate and adsorbed. Then, the clean and pure airflow passes through the outer surface of the plastic burning plate, enters the clean air box through the inner cavity of the plastic burning plate, and is discharged through the exhaust duct. With the continuous use of the
, the dust on its outer surface gradually increases. So how to clean the plastic fired board? It is controlled by an electronic control device to automatically select the plastic burning plate that needs to be cleaned, trigger the opening of the blowing valve, and inject compressed air into the inner cavity of the sintering plate to quickly blow away the dust accumulated on the outer surface of the plastic burning plate. The dust falls into the hopper under the action of airflow and gravity, achieving the purpose of cleaning the surface dust of the plastic plate.
The superiority of Yaoxian sintered plate dust collector products
(1) The plastic fired plate dust collector belongs to the surface filtration method, with high dust removal efficiency. The dust concentration in the exhaust gas is usually less than 10mg/m3, and it also has good dust removal effect on fine dust particles.
(2) The pressure loss of the plastic fired plate dust collector is stable. In the early stage of use, due to the lack of dust penetrating into the interior of the plastic fired plate, the pressure loss increases rapidly but quickly stabilizes.
(3) The filter element of the plastic fired plate dust collector has a rigid wavy porous structure, which greatly improves the dust removal effect.
(4) Plastic fired board is a rigid body that is not easily deformed. Its surface and gaps are treated with fluorinated resin, making it suitable for handling high moisture or oil content dust.
(5) Compact structure, small footprint, and volume only about one-third of traditional bag filters.
(6) The plastic fired board dust collector is anti-static, acid and alkali resistant, moisture resistant, wear-resistant, and has a service life of over 10 years.
