The principle of CO catalytic combustion device is to rapidly oxidize hydrocarbons in organic waste gas into water and carbon dioxide under low temperature conditions under the action of catalyst, achieving the purpose of
Waste Gas Treatment. The catalytic combustion process is carried out in a catalytic combustion device. Organic waste gas is preheated to 200-400 ℃ through a heat exchanger before entering the combustion chamber. When passing through the catalyst bed, the molecules of hydrocarbons and oxygen molecules in the mixed gas are adsorbed on the surface of the catalyst and activated. Due to surface adsorption reducing the activation energy of the reaction, hydrocarbons and oxygen molecules rapidly oxidize at lower temperatures, producing carbon dioxide and water
Advantages of Yaoxian Catalytic Combustion CO Equipment
① The CO catalytic combustion device is fully monitored by a PLC control system during operation, which is easy to operate and can achieve fully automatic control without the need for manual labor. Moreover, it greatly reduces the unstable factors during the operation of the catalytic combustion device, making it safe and reliable;
② By adopting thermal cycling technology, the heat recovery rate is ≥ 95%, which not only saves energy but also greatly reduces operating costs;
③ Yaoxian Environment insists on using excellent technology and high-quality raw material production equipment, and ensures that the service life of the catalytic combustion device is 10-15 years;
④ The honeycomb ceramic carrier catalyst impregnated with precious metals palladium and platinum has a large specific surface area, low resistance, and high purification rate;
⑤ Our catalytic combustion equipment has a purification efficiency of over 98% and does not produce secondary pollutants such as NOx;
⑥ Small footprint, only 70%~80% of similar products in the same industry;
⑦ The device only takes 15-30 minutes to start and heat up to the ignition temperature, consuming only the power of the fan. It automatically compensates when the concentration is low;
⑧ The safety protection measures meet the standards, equipped with flame retardant system, explosion-proof pressure relief system, and over temperature alarm system.
