The Yaoxian pulse bag filter is a new and more efficient pulse bag filter that is improved on the basis of the bag filter. The modified pulse bag filter retains the advantages of high purification efficiency, large gas processing capacity, stable performance, easy operation, long filter bag life, and low maintenance workload. Pulse bag filter is widely used in smoke control and dust removal systems for woodworking, food, medicine, electronics, hardware, cement, building materials, ceramics, electronics, chemical industry, footwear, casting, plastics, metallurgy, electricity, leather, food, mechanical processing, ironmaking plants, steelmaking plants, ferroalloy plants, refractory plants, power plants, mining screening, embryo drying, mixing and stirring, polishing, etc.
Working principle of Yaoxian pulse bag filter
The pulse bag filter is composed of an ash hopper, an upper box, a middle box, a lower box, and other parts. The upper, middle, and lower boxes are divided into compartments. During operation, dusty gas enters the ash hopper through the air inlet duct. Coarse dust particles directly fall into the bottom of the ash hopper, while fine dust particles enter the middle and lower boxes upwards with the turning of the airflow. Dust accumulates on the outer surface of the filter bag, and the filtered gas enters the upper box to the clean gas collection pipe exhaust duct, and is discharged to the atmosphere through the exhaust fan.
① High dust removal efficiency: generally above 99%, the dust concentration in the gas at the outlet of the dust collector is within 10mg/m ³, and it has a high classification efficiency for fine dust with submicron particles;
② Wide range of air flow processing: small ones can reach up to tens of thousands of cubic meters in just 1 minute, while large ones can be used for dust removal of industrial furnace flue gas, reducing the emission of atmospheric pollutants;
③ Simple structure: low operating cost, easy maintenance and operation;
④ Strong high-temperature resistance: When using glass fiber, polytetrafluoroethylene, and P84 high-temperature resistant filter bags, they can operate under high temperature conditions above 200 ℃;
⑤ Authoritative certification safeguards: Compliant with ISO management system certification, passed ISO9001 and ISO14001 certifications. Every device must undergo strict quality inspection before leaving the factory, meet environmental acceptance standards, and ensure quality and safety.
