Industrial high-temperature resistant dust collector

Basic Info

Brand: yaoxian

Additional Info

Transportation: Ocean,Land,Air,Express,Others

Product Description

The volume of high-temperature bag filter is relatively small, and it is flexible in operation. The processing air volume can range from millions of cubic meters per hour to hundreds of thousands of cubic meters per hour, and it can be directly installed indoors. Structurally speaking, it is relatively simple and runs very stably. It can use the gravity and inertia of dust particles to separate coarse particles in advance, reducing the dust load on the filter bag. Adopting 316L stainless steel filter material with good dust removal performance to improve various technical indicators.

Working principle of high-temperature resistant dust collector

The high-temperature resistant dust collector is a filtering type dust removal equipment based on the filtering principle, which uses the 316L stainless steel filter material developed by Yaoxian to filter out dust in the gas.

Dust removal process: The dusty gas enters the middle box through the air inlet, enters the bag from outside, and the dust is blocked on the surface outside the filter bag. The purified air enters the bag and then passes through the cloth

The upper part of the bag enters the upper box and is finally discharged through the exhaust pipe.

Advantages of High Temperature Dust Collector

Ultra low emissions: implement enterprise standards that require higher requirements than national standards;

Super suction: Good dust collection effect, easy to handle various types of dust, suitable for hundreds of working conditions;

High filtration accuracy: filtration accuracy of 0.3 μ m, filtration efficiency of 99.99%, air leakage rate<0.1%;

Long service life: thorough dust cleaning, stable operation, and more durable filter material.

Smooth design: The sinking flow structure layout is uniform, with high density and a dust removal efficiency of up to 99.99%;

High performance filtration: can meet special working conditions such as anti-static, flame retardant, oil and water resistance, ultra-fine dust, etc.

Long service life: Good wear resistance, stable operation, and more durable.
